Data Cookbook

An ever-growing collection of code blocks to perform useful data manipulation and plotting functions with standard Python libraries. This is mostly for my own self-reference, but possibly useful to others.

Bash

sed

Delete a line matching a pattern

sed '/some_string/d' $FILE

make

make is a beautiful piece of software that I continuously forget how to use. A few reminders for myself are below.

Basic Makefile

first_basic_component:
  command1 some args an_output
  command2 an_output the_second_output

# component 2 depends on first_basic_component
component2: first_basic_component
  command3 the_second_output

Using conda envs in Makefiles

.ONESHELL:

SHELL = /bin/bash

CONDA_ACTIVATE=source $$(conda info --base)/etc/profile.d/conda.sh ; conda activate ; conda activate

conda-component:
  conda activate usefulenv
  python some_file.py

Using loops in Makefiles

Weirdly, bash needs $$ as a variable indicator instead of $ when called by make

some_loop_output:
  for i in *.ext; do command1 $${i}; done

Python

These code snacks describe useful features of Python 3+ that aren’t always emphasized.

Force only named arguments to functions

In the below example, arguments following the splat * must be supplied as named arguments.

This is somewhat intuitive if you’re used to Pythons splat operator for *args or **kwargs. Here, the lonely splat “catches” positional arguments passed to the function after its introduction in the definition string.

def function(positional, *, named_only0, named_only1):
  # do some things
  return

def only_takes_named_args(*, named_only0, named_only1):
  # do some things
  return

This is useful when defining functions that may have arguments added and removed over time, explicitly preventing code from relying on the positional order.

logging

The python logging module offers granular control over user facing feedback.

Generally, we want to create a logger object for each module with the convention:

import logging

logger = logging.getLogger(__name__)
logger.setLevel(logging.INFO) # or logging.DEBUG etc. to set logger priority

logger.debug("This is a low priority statement, useful for debugging.")
logger.info("This is a medium priority statement, issued during normal program behavior.")
logger.warn("This is a high priority statement, not emitted during normal behavior.")

Using logging with IPython kernels can get tricky. In general, the following settings are sufficient to override any kernel defaults and give you the expected behavior.

import logging
import sys
logging.basicConfig(level=logging.INFO, stream=sys.stdout) # note level can be set as desired

Numpy

Preserve array dimensionality when slicing

When slicing a plane i from a multidimensional array A, use A[i:i+1,...] to preserve the array dimensionality with an empty dimension of size 1.

import numpy as np
A = np.random.random(5,5,5)
i = 0

A[:,i,:].shape # (5,5)
A[:,i:i+1,:].shape # (5,1,5)

Add an empty dimension by indexing

You can add an empty dimension of size 1 to an np.ndarray by passing None to one of the axes while indexing.

A = np.random.random((3,3))

B = A[:, :, None]
print(B.shape) # (3, 3, 1)

C = np.expand_dims(A, -1)
print(C.shape) # (3, 3, 1)

np.all(B == C) # True

Pandas

Split a column by a text delimiter

Use .str.split

# split by a '-' delimiter
# split is a pd.DataFrame, with each delimited column separated out
split = df.str.split('-', expand=True)

Replicate each row in a DataFrame N times

Use the .values attribute of a DataFrame and np.repeat

N = 3 # times to replicate
newdf = pd.DataFrame(np.repeat(df.values, N, axis=0))
newdf.columns = df.columns

Sort a DataFrame by multiple columns

Use the sort_values method of DataFrames.

df.sort_values(['a', 'b'], ascending=[True, False])

Credit

Check if rows are equal to an array-like vector

Given an array-like vector v with same dimensionality as rows in a DataFrame df, check which rows in df are equal to v.

df = pd.DataFrame([[0,1],[2,3],[4,5]], columns=['A', 'B'])
v = np.array([0,1])
(df == v).all(1) # checks for boolean True across columns

Credit

Matplotlib / Seaborn

Create editable, uncropped PDF exports

import matplotlib
# ensure text in PDF exports is editable.
matplotlib.rcParams['pdf.fonttype'] = 42
matplotlib.rcParams['ps.fonttype'] = 42
# prevent the PDF from being clipped to the "figsize".
# NOTE: this is different than `plt.tight_layout()`
# despite the similar name.
matplotlib.rcParams['savefig.bbox'] = 'tight'

Rotate Seaborn axis labels

g = sns.barplot(...)
g.set_xticklabels(g.get_xticklabels(), rotation=45)

Plot a line with a continuous color variable

Use a matplotlib.collections LineCollection to plot a set of smaller lines each with a different color, as desired.

StackOverflow Credit

import numpy as np
from matplotlib import pyplot as plt
from matplotlib.collections import LineCollection

x  = np.sin(np.linspace(0, 2*np.pi, 100))
y  = np.cos(np.linspace(0, 2*np.pi, 100))
t = np.linspace(0,1,x.shape[0]) # your "time" variable

# set up a list of (x,y) points
points = np.array([x,y]).transpose().reshape(-1,1,2)
print points.shape  # Out: (len(x),1,2)

# set up a list of segments
segs = np.concatenate([points[:-1],points[1:]],axis=1)
print segs.shape  # Out: ( len(x)-1, 2, 2 )
                  # see what we've done here -- we've mapped our (x,y)
                  # points to an array of segment start/end coordinates.
                  # segs[i,0,:] == segs[i-1,1,:]

# make the collection of segments
lc = LineCollection(segs, cmap=plt.get_cmap('viridis'))
lc.set_array(t) # color the segments by our parameter

# plot the collection
fig, ax = plt.subplots(1,1)
ax.add_collection(lc) # add the collection to the plot
ax.set_xlim(x.min(), x.max()) # line collections don't auto-scale the plot
ax.set_ylim(y.min(), y.max())

Connect two points with a curve

To connect two points in a plot with a curved line, we use scipy.interpolate.CubicSpline to interpolate a continuous series of points along a cubic function between the two points.

from scipy.interpolate import CubicSpline

points = np.array(
  [
    [0, 0],
    [1, 0],
  ],
)

# draw curve connecting start and destinations
xvals = np.linspace(x[0], x[1], 100)
# generate a coordinate at the midpoint to set the middle
# position of our arc
x_coords = [
  points[0, 0],
  points[0,0] + (points[1,0]-points[0,0])/2,
  points[1,0],
]

# ensure that the x_coords sequence is increasing
if x_coords[-1] < x_coords[0]:
    x_coords = x_coords[::-1]

# set a midpoint a bit above the two lower points
y = [0, 0.1, 0]

# generate smoothed values
spline = CubicSpline(x_coords, y)
y_smooth = spline(xvals)

# plot the original points
ax.scatter(points[:, 0], points[:, 1])

# plot the smooth curve
ax.plot(xvals, y_smooth, color='lightgray', linestyle='--', alpha=0.5,)
ax.set_ylim(bottom=0.05, top=0.15)
ax.set_xlim(-0.1, 1.1)

Add a label to heatmap colorbars in `seaborn`

seaborn.heatmap(data,
  cbar_kws={'label': 'colorbar title'})

Remove space between subplots

This is useful when plotting a grid of images.

H, W = 2, 2
fig, ax = plt.subplots(H, W)
fig.subplots_adjust(hspace=0.020,
                    wspace=0.00005)
for i in range(4):
  ax[i//2, i%2].imshow(I)
  ax.set_xticks([])
  ax.set_yticks([])

Remove axis spines from a `matplotlib` plot

fig, ax = plt.subplots(H, W, figsize=(h, w))
ax[idx].spines['right'].set_visible(False)
# `.spines` keys are {'left', 'right', 'top', 'bottom'}

Animate an image

from matplotlib import animation, rc

fig, ax = plt.subplots(1, 1, figsize=(10,10))
# remove white frame around image
fig.subplots_adjust(left=0, bottom=0, right=1, top=1, wspace=None, hspace=None)

im = ax.imshow(data, animated=True)


def updatefig(idx):
    im.set_array(new_data_iterable[idx])
    return im

anim = animation.FuncAnimation(
  fig, # figure with initialized artists
  updatefig, # updating function
  frames=100, # number of iterations, passes `range(0, frames)` to `updatefig`
  interval=1e3/30, # ms between frames, i.e. 1e3/FPS for a FPS argument
  blit=True) # drawing optimization

# if in a Jupyter notebook, the HTML module can display the animation inline
from IPython.display import HTML
HTML(anim.to_html5_video())

Add a row/column color legend to seaborn clustermap

Credit

# define some row clusters
row_clusters = get_row_clusters(data) # np.ndarray, np.int

# set up a LUT to assign colors to `row_clusters`
pal = sns.color_palette('tab20')

# make a clustermap
clmap = sns.clustermap(
  ...,
  row_colors = pal[row_clusters]
)

for label in np.unique(clusters):
    clmap.ax_col_dendrogram.bar(0,
                                0,
                                color=pal[label],
                                label=label,
                                linewidth=0)
clmap.ax_col_dendrogram.legend(loc="center", ncol=5, frameon=False)

# note that the usual .ax_col_dendrogram.set_visible(False)
# will also hide our new legend.
#
# hides the dendrogram while preserving the legend.
cm.ax_col_dendrogram.set_ylim(0,0)
cm.ax_col_dendrogram.set_xlim(0,0)

Add a second set of xticklabels to a seaborn heatmap

fig, ax = plt.subplots(1, 1, ...)

sns.heatmap(
  ...,
  ax=ax
)

# clone the x-axis
ax2 = ax.twiny()
ax2.set_xlim(ax.get_xlim())
ax2.set_xticks(ax.get_xticks())
ax2.set_xticklabels(SOME_NAMES_HERE)

# clean up the plotting aesthetics introduced by the second axis
plt.grid(b=None)

for x in ['top', 'bottom', 'right', 'left']:
    ax.spines[x].set_visible(False)
    ax2.spines[x].set_visible(False)

Generate box plots where outline colors match the fill hue

It’s often hard to see the colors of a hue in a boxplot if the data distribution is compact. We can change the outline color for the boxes to match the inner fill to make the colors easier to see.

StackOverflow

import matplotlib.pyplot as plt
import matplotlib.colors as mc
import colorsys
import seaborn as sns

def lighten_color(color, amount=0.5):
    """
    Generate a slightly lighter version of a specified color.
    These often look nice as outlines.
    credit: @IanHincks
    """
    try:
        c = mc.cnames[color]
    except:
        c = color
    c = colorsys.rgb_to_hls(*mc.to_rgb(c))
    return colorsys.hls_to_rgb(c[0], 1 - amount * (1 - c[1]), c[2])

# make a box plot
sns.boxplot(
    data=some_df,
    x='something',
    y='something_else',
    hue='third_thing',
    ax=ax
)

# iterate over every artist in the axis and change the outline colors
# to match the fill colors
for i,artist in enumerate(ax.artists):
    # Set the linecolor on the artist to the facecolor, and set the facecolor to None
    # omit `lighten_color` to make the outline flush with the box
    col = lighten_color(artist.get_facecolor(), 1.2)
    artist.set_edgecolor(col)

    # Each box has 6 associated Line2D objects (to make the whiskers, fliers, etc.)
    # Loop over them here, and use the same colour as above
    for j in range(i*6,i*6+6):
        line = ax.lines[j]
        line.set_color(col)
        line.set_mfc(col)
        line.set_mec(col)
        line.set_linewidth(0.5)

Jupyter

These snippets make life easier inside Jupyter notebooks.

Add a python `virtualenv` as a Jupyter kernel

# install ipykernel if it is not installed already
pip install ipykernel
# add the kernel to the jupyter kernelspec
export KERNEL_NAME="my_virtualenv"
python -m ipykernel install --user --name=${KERNEL_NAME}

PyTorch

Force cuDNN initialization

PyTorch loads cuDNN lazily, only initializing cuDNN after you call the first convolution in a program. This can occassionally lead to errors if PyTorch has already exhausted onboard CUDA memory when establishing the main cache. Sometimes, this error can be resolved simply by forcing cuDNN to load upon program initiation. This is accomplished by running a single convolution operation on the CUDA device.

def init_cudnn():
    s = 16
    device = torch.device('cuda')
    torch.nn.functional.conv2d(
      torch.zeros(s, s, s, s, device=device),
      torch.zeros(s, s, s, s, device=device),
    )
    return

Virtual Environments

You should probably set up all projects with their own python virtual environment for reproducibility. Unfortunately, these don’t always play nicely with cluster environments if you need multiple python versions. Here are a few tips to make life easier.

Generate a hard-copy virtual environment

If you want to use a python version that’s not installed globally on every node in a cluster, you’ll want to copy rather than link the necessary base python binaries and libraries.
This is simple enough using venv in python>=3.3.

export PY_VER="some_python_version"
export ENV_NAME="some_environment_name"
# `--copies` with copy the relevant python binaries
${PY_VER} -m venv --copies ${ENV_NAME}
# however, it *won't* copy the standard library!
# so you'll get funny `ModuleNotFoundError`s if you run on
# a node that doesn't have ${PY_VER} in `/usr/lib` et. al.
cp -Rv /usr/lib/${PY_VER}/* ${ENV_NAME}/lib/${PY_VER}/
# you'll also have to set the PYTHONPATH and PYTHONHOME manually
# when you activate the venv on cluster nodes
# e.g.
export PYTHONPATH="$(realpath ${ENV_NAME})/lib/${PY_VER}:$(realpath ${ENV_NAME})/lib/${PY_VER}/lib-dynload"
export PYTHONHOME=${PYTHONPATH}
# we can add these to `bin/activate` to make life easier
export TEST='# set PYTHONPATH and PYTHONHOME to account for copied standard library\nexport PYTHONPATH="/home/jacob/bin/envs/scvi-tools-0.9/lib/python3.9"\nexport PYTHONPATH="/home/jacob/bin/envs/scvi-tools-0.9/lib/python3.9/lib-dynload"\nexport PYTHONHOME=${PYTHONPATH}\n#these will be reset to the original values by `deactivate()` above'
cp ${ENV_NAME}/bin/activate ${ENV_NAME}/bin/activate.backup
sed -i s/export\ PS1\nfi/export\ PS1\nfi\n\n${TEST}/g ${ENV_NAME}/bin/activate

Genomics Tools

Genomics has its own set of standard tools, and it can be baffling to remember all the useful one-liners each tool offers. Here are some useful snippets to bring some sanity to bioinformatics workflows.

NCBI Datasets

Acquiring information about genes of interest (e.g. expressed sequences, encoded proteins) is a common task in genomics. Going from a list of gene symbols to a set of relevant sequences in FASTA file used to be a bit of a pain.

The new NCBI Datasets tool is surprisingly easy to use and delivers all the information you could want on a given gene symbol.

For example, if we want to get the proteins endoded by the myogenic regulatory factors, we can do so in a couple lines of bash.

datasets download gene symbol --taxon mouse \
	Myod1 Myog Myf5 Myf6
unzip ncbi_dataset.zip
less ncbi_dataset/data/protein.faa

GSE/SRA-tools

Most next-generation sequencing data generated in the USA is submitted to the Gene Expression Omnibus. Getting access to the raw sequencing reads is a bit trickier than you’d think. For collecting data from GEO, we largely rely on sra-tools.

Download FASTQs associated with a GEO submission

There are a few different ways to get raw data from a GEO submission, each with their own plusses and minuses.

(primary option) prefetch & fastq-dump

The best way to get .fastq data in uncompressed format is to prefetch all the related SRR tokens for a given SRA project ID, then use fastq-dump to convert the .sra cache to .fastq.

PROJECT_ID=PRJNA600730
# get the SRR tokens associated with a project
esearch -db sra -query $PROJECT_ID  | efetch --format runinfo | cut -d ',' -f 1 | grep SRR > SRR_names.txt
# prefetch all the SRR tokens. `--option-file` reads arguments sequentially from a text file.
# the precache gets stored in your sra directory, often ~/ncbi/sratools/
prefetch --option-file SRR_names.txt
# convert to fastq -- this has to be done sequentially, or you can use `parallel`
# fastq-dump will use the precached sra files by default
for i in $(cat SRR_names.txt); do echo $i; fastq-dump --split-files ${i}; done

(secondary option) fastq-dump direct download

This one-liner will find all the FASTQ files associated with a project in GEO then use fastq-dump to download associated reads as .fastq.gz files. The main advantage of this approach is on-the-fly compression with gzip, reducing the total storage requirements for a given GSE download.

The main downside is that it’s often, painfully, painfully slow to the point of unusability on large datasets. I’m not sure what the etiology here is, but SRA seems to acknowledge the issue and released fasterq-dump as an alternative. Unfortunately, fasterq-dump seems pretty buggy and tends to crash mid-way through large downloads with no option for recovery.

Biostars Credit

 # set a project ID
PROJECT_ID=PRJNA600730
esearch -db sra -query $PROJECT_ID  | efetch --format runinfo | cut -d ',' -f 1 | grep SRR | xargs fastq-dump --split-files --gzip

Get metadata for samples in a GEO submission

GEO is a beautiful resource, but the lack of structured metadata can be a challenge as a user. Usually, submitters include useful filenames in their processed data, or include a metadata CSV as a component of the processed data. Unfortunately, this isn’t always the case. Sometimes, metadata exists only in the GSM* entry for each individual sample.

In these cases, we can extract the relevant data by parsing the text with GEOparse.

pip install GEOparse

And usage:

gse = GEOparse.get_GEO(geo="GSE1563", destdir="./")

# `gse.gsms` is a `dict` mapping GSM_str : gsm_object
first_key = list(gse.gsms.keys())[0]
gsm_obj = gse.gsms[first_key]
# gsm_obj has a .metadata dictionary attribute
# gsm_obj.metadata has keys corresponding to section of a GSM webpage, like
# "treatment_protocol_ch1" or "description"
# the values are lists with str values of text metadata

Bioinformatics

bustools

bustools is performs cell barcode and UMI demultiplexing from kallisto pseudoalignments for single cell sequencing. The documentation is a little sparse, so here we add a bit more color.

Extract cell barcode, UMI reads as a table

bustools text <input.bus> -p <output_file> will convert a BUS file into a simple TSV. The columns aren’t documented though!

After investigating the source code here, we found that the outputs are:

cell_barcode  umi equivalence_class count

where equivalence_class is a transcript equivalence class in the kallisto index.

Files do not have a header, so example output is plain text similar to:

GACCGTTCAGCTAACC        GCAAGCATGCGT    760     1
ATTAGTCCAGCAATAA        ACTCTCAGTCAC    718     1
CTTTAGGCAAACTGCC        AACCTTTGTCTC    798     1
GGCAAGCCAAGTGTTT        AAAAGGTAAGAA    797     1

LaTeX

I love LaTeX. LaTex does not love me back. Here are some snippets to make our relationship more functional.

Use if/then control flow in a LaTeX build

\usepackage{etoolbox}
% defines \newtoggle, \settoggle
\newtoggle{somevar} % set a new boolean variable
\toggletrue{somevar}
\togglefalse{somevar}

% run an if then
\iftoggle{somevar}{
  % do thing
}{
  % else, do other thing or blank for nothing
}

Generate a custom bibtex style

# outputs
#   some_name.dbj - instructions for making a `bst`
#   some_name.bst - compiled `bst`
latex makebst
# to remake a `bst` from the `dbj`
tex some_name.dbj # outputs some_name.bst

Remove numbers or citation labels from reference list

SE Credit

\makeatletter
\renewcommand\@biblabel[1]{}
\makeatother
% we can also replace numbers with a common character, like a bullet
\makeatletter
\renewcommand\@biblabel[1]{\textbullet}
\makeatother

Customize figure captions

\usepackage{caption}
% remove separator between "Figure XYZ" and caption.
% print the figure number, but no caption
% useful for separating figures and captions in journal proofs
% e.g. "Figure 1", the caption text is suppressed
\captionsetup{labelsep=none,textformat=empty}
% use normal caption text, colon figure separator
% e.g. "Figure 1: Caption text here"
\captionsetup{labelsep=colon,textformat=plain}

Suppress graphics

Journals often want captions and figures separated in a final proof. We can insert captions without graphics by redefining the includegraphics command.

\renewcommand{\includegraphics}[2][]{}

Ensure figures and tables only appear after the insert position

The flafter package prevents any floats (figures, tables) from being presented above the position in the code where they are inserted. This is useful for ensuring a float appears below the relevant section title, or to ensure it doesn’t insert too early in the paper and give away your punchline before you’re ready.

\usepackage{flafter}

Shrink pdflatex output size

pdflatex tends to render huge PDF outputs. My understanding is that pdflatex is very conservative and applies no compression scheme. Substantial improvements in the file size can be found with loseless or modest lossy compression.

Ghostscript is installed by default on most Unix systems and does a good job of reducing file size on its own.

gs \
  -sDEVICE=pdfwrite \
  -dCompatibilityLevel=1.5 \
  -dPDFSETTINGS=/printer \
  -dNOPAUSE -dQUIET \
  -dBATCH \
  -sOutputFile=small.pdf big.pdf

The /printer argument will render 300 dpi compressed images that generally look great. If you need more compression, try swapping /ebook in place of printer. The images will still be legible, but you’ll almost certainly notice compression artifacts.

Another approach is to use a third-party tool pdfsizeopt.

After installation, compression is a one-liner.

/path/to/pdfsizeopt big.pdf

pdfsizeopt tends to get a smaller file size with better Ghostscript with the /printer setting, but it takes much longer to execute.

Docker

docker is a “container” system that acts as a lightweight virtualization layer. By default, docker accesses a Unix socket and needs to be run with superuser permissions.

Grabbing a container from dockerhub

sudo docker pull someorg/someimage

Running the docker image

sudo docker run someorg/someimage echo "this will run in the image"

If you want to open an interactive shell, you can use the -it flag.

sudo docker run -it someorg/someimage

Using the host (i.e. local) filesystem inside the virualized image requires you to mount it to a virtual directory with the -v argument.

sudo docker run \
  -v /local/path/to/code:/code \
  -v /local/path/to/data:/data_path_in_container \
  someorg/someimage python /code/my_script.py --data_path /data_path_in_container

Jacob C. Kimmel

Co-founder & President @ NewLimit. Interested in aging, genomics, imaging, & machine learning.

Data Cookbook

Data Cookbook

Bash

sed

Delete a line matching a pattern

make

Basic Makefile

Using conda envs in Makefiles

Using loops in Makefiles

Python

Force only named arguments to functions

logging

Numpy

Preserve array dimensionality when slicing

Add an empty dimension by indexing

Pandas

Split a column by a text delimiter

Replicate each row in a DataFrame N times

Sort a DataFrame by multiple columns

Check if rows are equal to an array-like vector

Matplotlib / Seaborn

Create editable, uncropped PDF exports

Rotate Seaborn axis labels

Plot a line with a continuous color variable

Connect two points with a curve

Add a label to heatmap colorbars in seaborn

Remove space between subplots

Remove axis spines from a matplotlib plot

Animate an image

Add a row/column color legend to seaborn clustermap

Add a second set of xticklabels to a seaborn heatmap

Generate box plots where outline colors match the fill hue

Jupyter

Add a python virtualenv as a Jupyter kernel

PyTorch

Force cuDNN initialization

Virtual Environments

Generate a hard-copy virtual environment

Genomics Tools

NCBI Datasets

GSE/SRA-tools

Download FASTQs associated with a GEO submission

Get metadata for samples in a GEO submission

Bioinformatics

bustools

Extract cell barcode, UMI reads as a table

LaTeX

Use if/then control flow in a LaTeX build

Generate a custom bibtex style

Remove numbers or citation labels from reference list

Customize figure captions

Suppress graphics

Ensure figures and tables only appear after the insert position

Shrink pdflatex output size

Docker

Grabbing a container from dockerhub

Running the docker image

Related Posts

Jacob C. Kimmel

Add a label to heatmap colorbars in `seaborn`

Remove axis spines from a `matplotlib` plot

Add a python `virtualenv` as a Jupyter kernel
